Oorspronkelijke prijs was: € 6.133,28.€ 2.759,98Huidige prijs is: € 2.759,98. incl.: € 3.339,58
13940 SKF | EAN: 7316571591292 | (GTIN14: 07316571591292)
Uitverkocht
Binnen enkele seconden geverifieerd om op factuur te kunnen betalen.
Large-size self-aligning ball bearings have two rows of balls, a common sphered raceway in the outer ring and two deep uninterrupted raceway grooves in the inner ring. They are insensitive to angular misalignment of the shaft relative to the housing. The annular lubrication groove in the outer ring and holes in the inner and outer rings facilitate ease of relubrication.
| Gewicht | 10,901 kg |
|---|---|
| Afmetingen | 29,5 × 29 × 7,3 cm |
| Structure group name |
Self-aligning ball bearings |
| Short description |
Large-size self-aligning ball bearing |
| Brand |
SKF |
| Pack Code |
Single package |
| EAN code |
7316571591292 |
| Pack gross weight |
10.901 kg |
| Pack height |
295 mm |
| Pack length |
290 mm |
| Pack width |
73 mm |
| Pack volume |
6.245 dm3 |
| Product net weight |
10.7 kg |
| Products per pack |
1 |
| UNSPSC code UNSPSC is a taxonomy of products and services for use in eCommerce, managed by GS1 US. It is a four-level hierarchy coded as an eight-digit number, two digits for each of the four hierarchical levels. |
31-17-15-32 |
| UNSPSC name |
Self aligning bearing |
| eClass code A eClass-code is a worldwide reference-data standard for the classification and unambiguous description of products and services established in industry, commerce, trade, and the service sector. eClass consists of a four-level hierarchy of classification classes (i.e. a tree structure). 8-digit class code (in ECLASS called: CodedName) consists of two digits for each of the four hierarchical levels. |
23-05-08-06 |
| eClass name |
Self-aligning ball bearing |
| Bore diameter Inner diameter of the bearing |
200 mm |
| Outside diameter |
280 mm |
| Width |
60 mm |
| Radial internal clearance Bearing internal clearance is defined as the total distance through which one bearing ring can be moved relative to the other in the radial direction (radial internal clearance) or in the axial direction (axial internal clearance) |
C3 Internal clearance larger than CN |
| Sealing |
Without |
| Bore type |
Cylindrical |
| Cage Steel cages can be used at operating temperatures up to 300 °C (570 °F) Sheet steel cages Stamped sheet steel cages are made of low carbon steel / Machined steel cages: Machined steel cages are normally made of non-alloyed structural steel / Brass Cages, Brass cages can be used at operating temperatures up to 250 °C (480 °F). / Sheet brass cages: Stamped sheet brass cages are used for some small and medium-size bearings / Machined brass cages: Most brass cages are machined from cast or wrought brass |
Machined metal (BRASS) |
| Relubrication feature |
With |
| Tolerance class |
Normal |
| Coating |
Without |
| Material bearing |
Bearing steel |
| Afmetingen | ||
| Eigenschap naam | Waarde | |
|---|---|---|
| Boring | 200 mm | |
| Buitendiameter | 280 mm | |
| Breedte | 60 mm | |
| Prestaties | ||
| Eigenschap naam | Waarde | |
| Dynamisch draaggetal | 60.5 kN | |
| Statisch draaggetal | 28 kN | |
| Referentietoerental | 4 300 r/min | |
| Grenstoerental | 2 600 r/min | |
| Eigenschappen | ||
| Eigenschap naam | Waarde | |
| Borging kenmerk, binnenring | Geen | |
| Positiekenmerk, lagerbuitenring | Geen | |
| Aantal rijen | 2 | |
| Type boring | Cilindrisch | |
| Kooi | Machinaal bewerkt metaal | |
| Radiale speling | C3 | |
| Tolerantieklasse | Normaal | |
| Materiaal, lager | Lagerstaal | |
| Coating | Zonder | |
| Afdichtingen | Zonder | |
| Smeermiddel | Geen | |
| Nasmeer kenmerk | Met | |
| Logistiek | ||
| Eigenschap naam | Waarde | |
| Nettogewicht van het product | 10.7 kg | |
| UNSPSC-code | 31171537 | |
| Beschrijving | Waarde | |
|---|---|---|
| Type boring | Cilindrisch | |
| Afmetingen | ||
| Parameter | Waarde | Beschrijving |
| d | 200 mm | Boring |
| D | 280 mm | Buitendiameter |
| B | 60 mm | Breedte |
| d1 | ≈ 229.3 mm | Diameter asborst binnenring |
| D1 | ≈ 257.8 mm | Diameter schouder buitenring |
| b | 8.3 mm | Breedte smeergroef buitenring |
| K | 4.5 mm | Diameter smeergat (buitenring) |
| r1,2 | min. 2.1 mm | Afmeting afschuining |
|
Afmetingen SKF-13940 |
Inbouwmaten SKF-13940 |
|
| Inbouwmaten | ||
| Parameter | Waarde | Beschrijving |
| da | min. 211 mm | Diameter asborst |
| Da | max. 269 mm | Diameter huisschouder |
| ra | max. 2 mm | Afrondingsstraal |
| Berekeningsgegevens | ||
| Parameter | Waarde | Beschrijving |
| C | 60.5 kN | Dynamisch draaggetal |
| C0 | 28 kN | Statisch draaggetal |
| Pu | 0.965 kN | Vermoeiingsbelastinggrens |
| 4 300 r/min | Referentietoerental | |
| 2 600 r/min | Grenstoerental | |
| α | 3 ° | Toelaatbare scheefstelling |
| kr | 0.015 | Berekeningsfactor |
| e | 0.19 | Grenswaarde |
| Y0 | 3.6 | Berekeningsfactor |
| Y1 | 3.3 | Berekeningsfactor |
| Y2 | 5.1 | Berekeningsfactor |
