S71912ACB/HCP4ADGA SKF | EAN: 7316574504107 | (GTIN14: 07316574504107)
Binnen enkele seconden geverifieerd om op factuur te kunnen betalen.
Double row angular contact ball bearings correspond, in their design and operation, to a pair of single row angular contact ball bearings in a back-to-back arrangement, while requiring less axial space, and are particularly suitable in applications where a stiff bearing arrangement is required. They can accommodate radial loads, axial loads in either direction and tilting moments. They can operate at very high speeds and are more suitable than deep groove ball bearings for supporting large axial forces.
| Gewicht | 0,423 kg |
|---|---|
| Afmetingen | 9,5 × 9,3 × 5,4 cm |
| Structure group name |
Super-precision angular contact ball bearings |
| Short description |
Double row angular contact ball bearing |
| Brand |
SKF |
| Pack Code |
Single package |
| EAN code |
7316574504107 |
| Pack gross weight |
0.423 kg |
| Pack height |
95 mm |
| Pack length |
93 mm |
| Pack width |
54 mm |
| Pack volume |
477.09 cm3 |
| Product net weight |
0.367 kg |
| Products per pack |
1 |
| UNSPSC code UNSPSC is a taxonomy of products and services for use in eCommerce, managed by GS1 US. It is a four-level hierarchy coded as an eight-digit number, two digits for each of the four hierarchical levels. |
31-17-15-31 |
| UNSPSC name |
Angular contact bearing |
| eClass code A eClass-code is a worldwide reference-data standard for the classification and unambiguous description of products and services established in industry, commerce, trade, and the service sector. eClass consists of a four-level hierarchy of classification classes (i.e. a tree structure). 8-digit class code (in ECLASS called: CodedName) consists of two digits for each of the four hierarchical levels. |
23-05-08-03 |
| eClass name |
Angular contact ball bearing |
| Bore diameter Inner diameter of the bearing |
60 mm |
| Outside diameter |
85 mm |
| Width |
26 mm |
| Sealing type |
Non-contact |
| Sealing |
Seal on both sides |
| Basic dynamic load rating The basic dynamic load rating Cr or Ca is the load which a bearing can theoretically endure for a basic rating life of one million revolutions. This is expressed as pure radial (Cr) load for radial bearings and pure axial (Ca) load for thrust bearings |
15.9 kN |
| Basic static load rating The basic static load rating C0r or C0a is defined as the load that results in a certain value of contact stress at the centre of contact of the most heavily loaded rolling element/raceway. C0r is indicate for radial load-, C0a is indicate for radial load rating. |
15.9 kN |
| Lubricant |
Grease |
| Tolerance class |
P4AU |
| Contact angle The contact angle is defined as the angle between the line joining the points of contact of the ball and the raceways in the radial plane, along which the combined load is transmitted from one raceway to another, and a line perpendicular to the bearing axis |
25° |
| Matched arrangement Angular contact ball bearing can be arrangement in different sets. ----- Back-to-back (O) or Face-to-Face (X) or Tandem (>>) ----- The O- and X-arrangements of two precision angular contact ball bearings makes it possible to take up axial loads in both directions. High axial loads in only one direction are supported by a tandem arrangement. |
Universal matching |
| QTY in matched set The number of bearings in one matched set angular contact bearings. |
2 |
| Contact type |
Normal contact (two-point contact) |
| Matched(ax.clearance/preload |
Extra light preload |
| Coating |
Without |
| Material bearing |
Hybrid |
| SKF performance class |
SKF Standard |
| Afmetingen | ||
| Feature Name | Value | |
|---|---|---|
| Boring | 60 mm | |
| Buitendiameter | 85 mm | |
| Breedte | 26 mm | |
| Contacthoek | 25 ° | |
| Prestaties | ||
| Feature Name | Value | |
| Dynamisch draaggetal | 15.9 kN | |
| Statisch draaggetal | 16.6 kN | |
| Opmerking | Neem contact op met SKF voor de mogelijke toerentallen | |
| Eigenschappen | ||
| Feature Name | Value | |
| Contacttype | Normaal contact (tweepuntscontact) | |
| Aantal rijen | 2 | |
| Type ring | Binnen- en buitenringen uit één stuk | |
| Ontwerp | Hogesnelheid B | |
| Universeel gepaard lager | Ja, O-opstelling (), X-opstelling (>>) | |
| Gepaarde opstelling | Universeel passend | |
| Aantal lagers in gepaarde set | 2 | |
| Gepaarde conditie (axiale speling/voorspanning) | Extra lichte voorspanning | |
| Tolerantieklasse | P4A | |
| Materiaal, lager | Hybride | |
| Coating | Zonder | |
| Afdichtingen | Afdichting aan beide zijden | |
| Type afdichting | Niet-slepend | |
| Smeermiddel | Vet | |
| Indicative product carbon footprint to manufacture | 1.32 kg CO2e | |
| Logistiek | ||
| Feature Name | Value | |
| Nettogewicht van het product | 0.367 kg | |
| eClass code | 23-05-08-03 | |
| UNSPSC-code | 31171531 | |
| Beschrijving | Waarde | |
|---|---|---|
| Universeel gepaard(e) lager(s) | Ja, O-opstelling (), X-opstelling (>>) | |
| Afmetingen | ||
| Parameter | Waarde | Beschrijving |
| d | 60 mm | Boring |
| D | 85 mm | Buitendiameter |
| B | 26 mm | Breedte |
| d1 | 68.94 mm | Diameter asborst binnenring (groot zijvlak) |
| d2 | 67.73 mm | Diameter asborst binnenring (klein zijvlak) |
| D2 | 78.36 mm | Uitsparingsdiameter buitenring (groot zijvlak) |
| D4 | 79.86 mm | Uitsparingsdiameter schouder van de buitenring (klein zijvlak) |
| r1,2 | min. 1 mm | Afmeting afschuining |
| r3,4 | min. 0.3 mm | Afmeting afschuining |
|
Afmetingen SKF-S71912-ACB/HCP4ADGA |
Inbouwmaten SKF-S71912-ACB/HCP4ADGA |
|
| Inbouwmaten | ||
| Parameter | Waarde | Beschrijving |
| da | min. 64.6 mm | Diameter aanlegvlak as |
| da | max. 68.3 mm | Diameter aanlegvlak as |
| db | min. 64.6 mm | Diameter aanlegvlak as |
| db | max. 67.1 mm | Diameter aanlegvlak as |
| Da | max. 80.4 mm | Diameter aanlegvlak lagerhuis |
| Db | max. 83 mm | Diameter aanlegvlak lagerhuis |
| ra | max. 1 mm | Afrondingsstraal |
| rb | max. 0.3 mm | Afrondingsstraal |
| Berekeningsgegevens | ||
| Parameter | Waarde | Beschrijving |
| C | 15.9 kN | Dynamisch draaggetal |
| C0 | 16.6 kN | Statisch draaggetal |
| Pu | 0.51 kN | Vermoeiingsbelastinggrens |
| To be calculated: Single bearing (22000) x speed reduction factor (see table below) | Bereikbaar toerental voor vetsmering | |
| To be calculated: Single bearing () x speed reduction factor (see table below) | Bereikbaar toerental voor olie-luchtsmering | |
| α | 25 ° | Contacthoek |
| Dw | 5.556 mm | Kogeldiameter |
| i | 2 | Aantal rijen |
| z | 30 | Aantal kogels (per lager) |
| VOORSPANNING EN STIJFHEID (X- OF O-OPSTELLING) | ||
| Parameter | Waarde | Beschrijving |
| A | Voorspanningsklasse | |
| G | 57 N | Voorspanning |
| 104 N/µm | Axiale stijfheid | |
| CORRECTION FACTORS FOR PRELOAD CALCULATION | ||
| Parameter | Waarde | Beschrijving |
| f | 1.11 | Correctiefactor is afhankelijk van lagerserie en -afmeting |
| f1 | 0.99 | Correctiefactor afhankelijk van contacthoek |
| f2A | 1 | Correctiefactor, voorspanning klasse A |
| fHC | 1.01 | Correctiefactor voor hybride lagers |
| FACTORS FOR EQUIVALENT BEARING LOAD CALCULATION | ||
| Parameter | Waarde | Beschrijving |
| e | 0.68 | Berekeningsfactor |
| Y1 | 0 | Axiale belastingfactor (enkel, tandem) |
| Y2 | 0.87 | Axiale belastingfactor (enkel, tandem) |
| Y0 | 0.38 | Axiale belastingfactor (enkel, tandem) |
| X1 | 1 | Radiale belastingfactor (enkel, tandem) |
| X2 | 0.41 | Radiale belastingfactor (enkel, tandem) |
| X0 | 0.5 | Radiale belastingfactor (enkel, tandem) |
| Y1 | 0.92 | Axiale belastingfactor (X- of O-opstelling) |
| Y2 | 1.41 | Axiale belastingfactor (X- of O-opstelling) |
| Y0 | 0.76 | Axiale belastingfactor (X- of O-opstelling) |
| X1 | 1 | Radiale belastingfactor (X- of O-opstelling) |
| X2 | 0.67 | Radiale belastingfactor (X- of O-opstelling) |
| X0 | 1 | Radiale belastingfactor (X- of O-opstelling) |
